SHROUD AND FAN OPTIONS
Understanding our Shroud and Fan Options
We offer a wide range of fans and shroud options for most of our radiators. Use the data on this page to help determine which shroud and fan package is right for your application.
What you need to know in order to select a fan and shroud for your application…..
If you are looking to purchase a complete package (Radiator/ Shroud/ Fans) you will first need to determine the maximum thickness the package can be. In most vehicles you would get this dimension by measuring the distance between your core support and your first point of interference at the motor (typically your pulleys). If you are looking for a fan package only You will want to measure the distance between the shroud mounting surface on the radiator out to the first point of interference at the motor (typically your pulleys). Our fan shroud packages are designed to fit specifically on Wizard Cooling radiators, there was no design intent for our shrouds to work with/ fit on/ or bolt to any other competitors products.
NEED HELP MAKING A SELECTION?
Call Us at 716-655-6760
| FAN PACKAGES: Ordered by PERFORMANCE by THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Fan/ Shroud Thickness | PACKAGE THICKNESS (Radiator, fan, & shroud/ Bracket) | Performance | Fan Mounting Type | Fan Description | SINGLE FAN $$ | DUAL FAN $$ |
| 2.00" | 5.00" | BEST | Bracket | Low Profile | $170 | $315 |
| 2.50" | 5.50" | BEST | Bracket | Medium Duty | $205 | $385 |
| 2.50" | 5.50" | GOOD (vehicles w/o A/C, 1" tube cores only) | Integrated Fan Shroud | Medium Duty | $335 | $560 |
| 3.00" | 6.00" | BEST | NON-Integrated Fan Shroud | Low Profile | $255 | $390 |
| 3.50" | 6.50" | GOOD | Integrated Fan Shroud | High Performance | $355 | $600 |
| 3.50" | 6.50" | BETTER (applications w/o A/C) | NON-Integrated Fan Shroud | Medium Duty | $290 | $460 |
| 3.50" | 6.50" | BEST (applications w/ A/C) | Bracket | High Performance | $225 | $425 |
| 3.50" | 6.50" | ABSOLUTE BEST (Best for any space greater than 3.5"/6.5") | NON-Integrated Fan Shroud | Brushless | $675 | $1150 |
| 3.75" | 6.75" | GOOD | Integrated Fan Shroud | Paddle Blade | $380 | $650 |
| 3.75" | 6.75" | BETTER | Bracket | Paddle Blade | $250 | $500 |
| 3.75" | 6.75" | ABSOLUTE BEST (Best for any space greater than 3.5"/6.5") | NON-Integrated Fan Shroud | Brushless | $675 | $1150 |
| 4.50" | 7.50" | GOOD | NON-Integrated Fan Shroud | High Performance | $310 | $500 |
| 4.50" | 7.50" | ABSOLUTE BEST (Best for any space greater than 3.5"/6.5") | NON-Integrated Fan Shroud | Brushless | $675 | $1150 |
| 4.75" | 7.75" | GOOD | NON-Integrated Fan Shroud | Paddle Blade | $325 | $600 |
| 4.75" | 7.75" | ABSOLUTE BEST (Best for any space greater than 3.5"/6.5") | NON-Integrated Fan Shroud | Brushless | $675 | $1150 |
